GLITTER 801A Battery Spot Welder Capacitor Energy Storage Pulse Welding Machine

GLITTER

(1 review) Write a Review
$89.99
GLITTER 801A Battery Spot Welder Capacitor Energy Storage Pulse Welding Machine
SKU:
JFBSW00011
UPC:
888107100409
Condition:
New
Availability:
Usually ships in 1 business days.
Ship From:
China Warehouse
Shipping Cost:
Order Checkout Calculating

Product Overview

User Manual(Click Here)

801A Machine Tutorial Video

801A Capacitor Energy-Storage Precision Pulse Spot Welder Super Energy-Gathered Pulse Technology

Features:

1. Compared to the traditional AC spot welding machine,the new-designed 801A capacitor energy-storage spot welder has no interfere to the electric circuit, no more tripping problems.
2.The 801A adopts the latest energy-gathered pulse welding technology, it has a great welding power, the welding spot is nice and elegant,ensuring you a reliable welding effect.
3.The maximum welding power of the machine can be up to 10.6 KW meeting the needs for large-batteries welding.
4.The welding power can be adjusted conveniently via two buttons according to the thickness of welding objects, the LED screen will display the welding parameters.
5.The machine is equipped with two super capacitors which have long working-life and large capacity, ensuring the low power-consumption and high output welding work.
6.The 'AT’automatic welding mode helps you finish the welding work efficiently.
7.Compatible with 7 series mobile welding pen.
8.The compact aluminum alloy shell can effectively dissipate heat.

Applications：

Production of small battery packs for mobile electronic devices.
Welding of lithium polymer batterycell phone battery and protective circuit board.
Spot welding leaders to different metal projects，such as iron,stainless steel, brass nickel,molybdenum and titanium.

Parameters :

Model :GLITTER 801A
Voltage Output :5.3V（Peak）
Voltage Input: AC 100-240V 50/60HZ
Peak Welding Energy :53J
Pulse Power :10.6KW（Peak）
Trigger Mode: AT
AT mode--automatic welding(no foot pedal control, suitable for welding
a large number of batteries for a long time).
Energy Grade: 0-99T
Welding Mode: Separated-style spot welding pen
Pluse Time :0~5mS
Preload Delay :20~50mS
Adapter Parameter :15V1.3A（Peak）
First Charging Time: 30~40(mins)

70A Separated Spot Welding Pen Welding Thickness:

Pure nickel welding to 18650 battery:0.05~0.15mm
Nickel-plated welding to 18650 battery:0.05~0.2mm
With fixed seat butt welding:0.3mm

Warranty Information

One Year Limited Warranty

Reviews

(1 review) Write a Review

1 Review Hide Reviews Show Reviews

  • 5
    Glitter 801a

    Posted by Wheelz Scooters on 8th Aug 2022

    Now let me start by saying my review is based on a working unit and unfortunately I initially got a bad unit from the get go so I was definitely a little unsettled when I'm trying a new product out that has no reviews and is brand new to the market and boasts the high specs that this welder does and claims to utilize technology that no other welder that's in it's class has. Well finally after about a week of being frustrated I got a working unit in! This thing is very powerful! I burnt holes into nickel strip that was pure and .25mm which is hard to do and no other brand for this price or any price close to it can put down amazing welds like this unit. I must warn you this unit requires to be charged up since it is a capacitor so it's best to allow at least 20 mins to let it charge up so what I do is I will plug it in first then prepare all my strips and cells and get everything ready and when I'm done it's charged and ready to go. The dual pen with the secondary swappable interface is awesome for doing pouch cells and the pens stay cool to the touch even 400 welds in and I honestly recommend this to anyone. I have had mine for almost 7 months now and it's welded some huge batteries and over 300 packs and it is still like it's brand new (minus the crack in display from my idiot self dropping the thing) forget sunkko or any of those crappy welders out there this welder is up there with the quality of K-welder. Super easy to use and it's simple setting options make for a awesome buy for $160. I can't wait to try out the other models they have once I can afford to get another welder. Check out my video review of this welder on YouTube just look up glitter spot welder by Wheelz Scooters Inc. and you can see how easy it is to get started welding today!!!
