GLITTER 801H+ Battery Spot Welder Capacitor Energy Storage Pulse Welding Machine

User Manual(Click Here)

801H⁺ Lifting Lithium Battery Welding Workbench For welding nickel on aluminum electrode

Features:

1.The high-frequency inverter energy storage super capacitor discharge technology eliminates the interference to the AC power supply, no switch tripping situation.

2.The patented energy storage control and low-loss metal bus technology maximizes the burst energy output of pulses.

3.The energy-gathering pulse formation technology controlled by the microcomputer chip ensures the formation of reliable solder nuggets in milliseconds.

4.Welding quality inspection device for monitoring and alarming the quality of welding points in batch welding operations.

5.Unique real-time display of welding pulse current, which can monitor each welding current and avoid false welding of points.

6.Innovative lifting mechanism to meet the needs of welding work pieces of different heights.

7.The dual welding tool mode is convenient for wide welding range of batteries and metal parts flexibly.

Application

Assemble ternary lithium battery pack

Assemble LiFePO₄ battery pack

Welding hardware

Repair electric vehicle

Battery product processing factory

Parameters

Capacitor storage voltage :6V（DC）

Max. pulse output power:24KW（Max.)

Max. welding energy (including line loss):480J

Energy level:0-99T

Trigger mode:Auto trigger AT/Foot pedal trigger MT

Pre-pressing delay time:100/200/300/400/500ms

Pulse time：20ms

Welding thickness：0.05~0.5mm (nickel plated)

First charge time：About 12 minutes

Adapter supply voltage：AC100-240V

Adapter parameter：16V4A(max.)

Charging mode：Constant current and voltage

Packing list:

1)801H+ welding machine *1 set；

2)75A welding pen(25²)*1 pair

3)73SA downward press welding head *1 set

4)801H+ adapter*1 pc

5)Foot pedal switch*1 pc

6)Welding pins for fixed head *4 pcs

7)75A welding pen electrodes(25²)*2 pairs

8)Mainframe fixed base*1 pc

9)L-type fixed bracket*1 pc

10)Lift table fixing screws*4 pcs

11)Elevating fixing screws*4 pcs

12)Hex wrench *2 pc

13)75A wrench*1 pc

14)Nickel aluminum composite sheet sample*10 pcs

15)Pure nickel sample*10pcs

16)Operation Manual*1 pc
